The heating element for electric kettle adopts die-cast aluminum alloy substrate and thick film resistor technology, integrated PID temperature control module and NTC temperature sensor, achieving 3 seconds fast heating, energy efficiency ≥ 96%, working temperature range 80℃-150℃, adapting to high-frequency continuous boiling needs, with IPX7 waterproof and anti-dry burning protection performance, supporting 800W-3000W power customization, scale corrosion resistance life of more than 30,000 hours, in line with EU CE certification, to meet the needs of efficient and stable heating in home and commercial scenarios.
Minimum order quantity: 1000
Delivery time: 15-25 days
Factory location: Zhongshan, Guangdong, China
Household electric kettles (such as Philips/Saeco/Philips), commercial large-capacity water boilers, hotel commercial electric tea boilers, medical equipment distilled water systems, laboratory constant temperature kettles, industrial hot drink machines (capsule coffee machines/tea machines), new energy vehicle on-board hot water systems, hotel commercial electric hot water equipment.
| Parameter | Specification Range |
|---|---|
| Power Range | 500W-3000W |
| Operating Voltage | 220V (single-phase, household standard); 380V (three-phase, commercial optional) |
| Resistance Value | 3Ω-50Ω (single unit or multi-unit combination, matched to power and voltage) |
| Operating Temperature | Surface: 120℃-200℃ (normal); Maximum withstand: 250℃ (short-term overload protection) |
| Material | Heating element: Nickel-chromium alloy (Cr20Ni80, Φ0.6mm-Φ2.0mm); Housing: 304/316 stainless steel (corrosion-resistant, thickness 0.8mm-2.0mm) |
| Dimensions | Length: 100mm-600mm; Diameter/Thickness: 20mm-100mm (compatible with instant water boilers and range hood heating slots) |
| Service Life | 5000h-12000h (normal use, no dry burning/limescale buildup) |
If you can provide accurate demand parameter information, we can give you a quote within 24 hours at the earliest.
