The electric heater heating element adopts high-purity nickel-chromium alloy heating wire and ceramic insulation skeleton, combined with a fully enclosed metal shell and anti-oxidation coating process, with high temperature resistance (600℃), corrosion resistance, excellent insulation and other characteristics, thermal efficiency ≥95%. Support single-end/dual-end power supply design, power coverage 1kW-30kW, adapt to PID intelligent temperature control (±2℃ accuracy), built-in anti-dry burning, overheating protection and leakage monitoring functions, life ≥80,000 hours. The product is CE, RoHS, UL certified, and can be customized in length, diameter and installation method. It is suitable for industrial ovens, pipeline heating systems and household appliances (air purifiers, heaters).
MOQ：1000PCS
Lead time：25days
Factory location: Zhongshan, Guangdong, China
For high-temperature durability, make these from nichrome (NiCr), Kanthal (FeCrAl), or silicon carbide (SiC).
When electricity flows through it, heat is produced.
Insulation made of stainless steel, iron, or ceramic helps to keep water, air, or debris from touching.
Insulation layer:
Ceramic insulation or magnesium oxide (MgO) powder helps retain heat and stop electrical leaking.
| Helical wire coils (e.g., in space heaters). | Space heaters, hair dryers | |
| U-shaped tubes (e.g., in water heaters). | Water heaters, boilers | |
| Cylindrical, sealed design (e.g., in furnaces). | Industrial furnaces, baseboard heaters | |
| Coiled wire with fins for increased surface area (e.g., oil heaters). | Radiators, underfloor heating | |
| High-intensity quartz tube with halogen bulbs (instant heat). | Hair straighteners, portable heaters |
Water heaters, electric stoves, space heaters, underfloor heating.
HVAC systems, industrial ovens, dryers.
Furnaces, boilers, metalworking equipment.
| 500W–15,000W (depends on use case) | Determines heating capacity. | |
| 120V, 240V, or 480V | Must match power supply. | |
| Varies (e.g., 38Ω for 240V/1500W) | Affects power output. | |
| Nichrome (cost-effective), Kanthal (high temp) | Corrosion and heat resistance. | |
| 600°C–1200°C (varies by material) | Critical for industrial use. |
If you can provide accurate demand parameter information, we can give you a quote within 24 hours at the earliest.
