electric fireplace heating element

Applications

Consumer Appliances: Decorative electric fireplaces, gas-assisted electric fireplaces, portable indoor heaters.
Industrial Equipment: Warehouse heating systems, agricultural greenhouse heating units, outdoor commercial heating devices.

Product parameters and specifications

Power range:
Home use: 800W–2500W (suitable for fireplaces, decorative flame effects)
Commercial use: 2500W–5000W (large flame simulation system for hotels/commercial spaces)
Working voltage: 110V/220V single-phase AC or 240V three-phase AC (global power grid compatible, error ≤±5%).

Resistance value: 4Ω–50Ω (accurately matched by voltage and power, error ≤±3%).

Working temperature:
Conventional model: continuous and stable operation of 150°C–300°C (self-limiting temperature design, anti-overheating).
High temperature model: short-term tolerance of 400°C (customized heat dissipation structure and ceramic coating required).

Material:
Heating element: stainless steel 304/316L (corrosion and oxidation resistance) or nickel-chromium alloy (NiCr, high temperature oxidation resistance).
Surface treatment: enamel coating (anti-oxidation, beautiful) or ceramic coating (high temperature resistance up to 600°C).

Optional technology: PTC ceramic chip (self-limiting temperature characteristics, no external thermostat required).

Dimensions:

Pipe diameter: Φ8mm–Φ30mm, length 100mm–1000mm (supports U-shaped, spiral or flat customization).

Flame simulation area: suitable for 50cm–200cm wide fireplaces, supports multi-stage heating partitions.

Service life: 15,000–50,000 hours (based on operating temperature and heat dissipation conditions, enamel coating extends life).

Customizable services: support power, voltage, flame color (RGB LED integration), explosion-proof certification, etc.

Core advantages

Safety and reliability:

Self-limiting PTC technology: automatically reduce power when the temperature exceeds the set value to prevent overheating and combustion, without the need for an external thermostat.
​​IP24 protection level: dustproof and splashproof, suitable for home environments with children/pets.
​​Automatic power off when tilting: power off immediately when the tilt angle is greater than 15°, in line with UL/CE safety standards.
​​Efficient heating and energy saving:
Thermal efficiency is ≥90%, electrical energy is directly converted into thermal energy, and energy consumption is reduced by 40% compared with gas fireplaces.
Thermal conductivity of nickel-chromium alloy heating element is ≥150W/m·K, and the temperature rises to 150°C within 3 minutes.
​​Realistic flame effect:

Multi-stage heating partition: simulates real flame dynamics and supports LED light source synchronous rendering (warm yellow/cold white light).
​​Ceramic reflective coating: evenly scatters heat, avoids local overheating, and improves visual comfort.
​​Long life and low maintenance:
The surface enamel/ceramic coating is corrosion-resistant and peeling-resistant, and its life is 2-3 times longer than that of ordinary resistance wire.
No moving parts design, maintenance-free cleaning (just wipe the surface dust).
​​Intelligent compatibility​​:
Supports Wi-Fi/Bluetooth remote control (APP adjusts temperature/flame mode), and is compatible with smart home systems.
Temperature and humidity sensors can be integrated to automatically adjust heating power to maintain indoor comfort.
​​Environmentally friendly and silent​​:
Zero emissions, no noise, in line with the EU ErP energy efficiency directive
