How to Replace Heating Element in a Maytag Dryer
Quick Overview of the Process
You can replace the heating element in your Maytag dryer by following a series of straightforward steps. This process requires attention to detail and a methodical approach. Here is a step-by-step outline based on manufacturer guidelines:
- Unplug your dryer to ensure complete safety.
- Remove the kick plate at the bottom by sliding a putty knife along the top edge to release the plastic clamps.
- Fold the kick plate out and down to access the heat shield.
- Unscrew and remove the heat shield on the right side.
- Locate the heating element in its open-front housing, usually fastened by two hex head screws.
- Remove the screws and disconnect the two wires attached to the heating element. Use needle nose pliers if needed.
- Slide the old heating element straight out. If you see a small plastic hose attached, disconnect it carefully.
- Clean the area thoroughly. Use a vacuum to remove dust and lint from the element housing and the underside of the dryer.
- Install the new heating element by reversing the removal steps. Make sure all wires and screws are secure.
- Optionally, clean the exhaust duct and outside vent to prevent future issues. Avoid accordion-style aluminum foil ducts and remove any lint-collecting screens from the exterior vent.
⚠️ Tip: Always double-check that you have reconnected all wires and secured all screws before reassembling the dryer.
Common mistakes during this process include failing to unplug the dryer, mishandling the heating element coil, or not reconnecting wires properly. You should also avoid stretching the coil or letting it touch itself, as this can cause malfunction. Take care to secure all screws and ensure the coil remains evenly spaced.
Why Replacing the Heating Element Matters
A faulty heating element in your Maytag dryer can cause several problems. You may notice that your dryer produces little or no heat, which leads to longer drying times and ineffective drying. This inefficiency forces your appliance to run longer, increasing energy consumption and reducing overall energy efficiency.
When you replace heating element components, you restore the dryer’s heating capability. This simple repair improves both performance and energy efficiency. If the heating element is the only issue, replacement is much more cost-effective than purchasing a new appliance. However, older dryers may still use more energy due to their age and design, even after a successful repair.
You should also consider a professional diagnosis if you suspect other issues, such as a faulty thermal fuse or thermostat. Addressing the heating element promptly helps you maintain optimal dryer performance and avoid unnecessary energy costs.
Signs Your Maytag Dryer Heating Element Needs Replacement
Common Symptoms of a Faulty Heating Element
Dryer Not Heating Up
You may notice your dryer drum spins, but your clothes remain cold and damp after a full cycle. This is a classic sign of a faulty heating element. When the heating element fails, your Maytag dryer cannot generate the heat needed to dry laundry. If you experience a non-heating dryer, you should investigate the heating element as a likely cause.
Clothes Take Too Long to Dry
If your clothes require multiple cycles to dry, the heating element may not be working efficiently. You might find that even after a standard drying time, items feel damp or warm but not fully dry. This symptom often points to a heating element that is partially damaged or losing effectiveness.
Dryer Shuts Off Prematurely
A faulty heating element can cause your dryer to overheat and shut off before the cycle completes. Overheating triggers safety features that stop the dryer to prevent damage. If your dryer stops unexpectedly, you should check the heating element and related components.
Diagnostic Steps for Maytag Electric Dryer
Visual Inspection of the Heating Element
Start by unplugging your Maytag electric dryer. Remove the back panel to access the heating element. Look for visible signs of damage, such as broken coils, burn marks, or discoloration. If you see any of these issues, you likely have a faulty heating element.
Using a Multimeter to Test Continuity
If you do not see obvious damage, use a multimeter to test the heating element for continuity. Set the multimeter to the lowest resistance setting. Touch the probes to the terminals of the heating element. A reading of zero or near zero indicates good continuity. If the multimeter shows no continuity, you need to replace the heating element. Appliance repair experts recommend this step as a standard method to confirm a faulty heating element.
Checking for Error Codes
Some Maytag dryers display error codes when a component fails. Check your user manual for a list of codes related to heating issues. If your dryer shows an error code, follow the troubleshooting steps provided by the manufacturer. Error codes can help you pinpoint whether the heating element or another part is causing the problem.
Tip: Always check related components, such as the thermal fuse and thermostat, during your inspection. These parts can also cause heating problems if they fail.
You should also verify that your dryer receives proper power. For electric models, make sure both legs of the 240-volt supply are active. If you have a gas dryer, confirm the gas supply valve is open and the gas valve coils function correctly. Avoid guessing the cause of the problem. Use these diagnostic techniques or consult a professional if you feel unsure.
Safety Precautions for Maytag Electric Dryer Repairs
Before you begin any appliance repair, you must prioritize safety. Working with electric dryers exposes you to electrical hazards and sharp components. Taking proper precautions protects you from injury and prevents damage to your Maytag dryer.
Disconnecting Power Safely
Unplugging the Dryer
You should always disconnect your Maytag electric dryer from its power source before starting any repair. This step eliminates the risk of electric shock. Locate the power cord at the back of your dryer. Firmly grasp the plug and pull it straight out from the wall outlet. Never attempt to repair or inspect your dryer while it remains plugged in. Even if you only plan to perform a quick check, unplugging the dryer ensures your safety.
Turning Off the Circuit Breaker
Sometimes, the power cord is difficult to reach, or you want an extra layer of protection. In these cases, turn off the circuit breaker that supplies electricity to your dryer. Find your home’s electrical panel and identify the breaker labeled for the laundry room or dryer. Switch it to the “off” position. This action guarantees that no electricity flows to the appliance during your repair.
⚡ Note: When testing components such as the thermal fuse, use electrical tape to insulate any temporarily bypassed wire connections. Make sure bare wires never touch the dryer cabinet. After testing, always restore safety components like the thermal fuse to their original state. These parts play a critical role in safe dryer operation.
Key steps for disconnecting power:
- Unplug the dryer from the wall outlet before any repair or diagnostic test.
- If you must bypass a component for testing, insulate wire connections with electrical tape.
- Prevent bare wire contacts from touching the dryer cabinet.
- Restore all safety components after testing to maintain safe operation.
Preventing Injury and Damage
Wearing Protective Gear
You should wear protective gear when working on your Maytag electric dryer. Gloves protect your hands from sharp edges inside the appliance. Safety glasses shield your eyes from dust and debris. These simple items reduce the risk of cuts and eye injuries during appliance repair.
Ensuring Proper Ventilation
Proper ventilation is essential when repairing your dryer. Open a window or door to allow fresh air into your workspace. This step helps disperse any dust or fumes released during the repair. Good airflow also keeps you comfortable and alert while you work.
🛡️ Tip: Keep your workspace clean and organized. Remove clutter and keep tools within easy reach. A tidy area helps prevent accidents and makes the repair process smoother.
By following these safety precautions, you protect yourself and your appliance. Safe practices ensure a successful repair and extend the life of your Maytag electric dryer.
Tools and Parts Needed to Replace Heating Element
Before you begin your Maytag dryer repair, gather all necessary tools and parts. Having the right equipment ensures a smooth and safe process.
Essential Tools for Maytag Dryer Repair
Phillips and Flathead Screwdrivers
You need both Phillips and flathead screwdrivers to remove and reinstall panels and components. These tools allow you to access the heating element and other internal parts. Choose screwdrivers with comfortable grips for better control.
Nut Driver or Socket Wrench
A nut driver or socket wrench helps you remove hex head screws that secure the heating element housing. These tools provide the torque needed to loosen or tighten fasteners without damaging them. You will find them essential for disassembling and reassembling your dryer.
Multimeter
A multimeter allows you to test the heating element for electrical continuity. This tool helps you confirm whether the element is faulty before you replace it. Set the multimeter to the lowest resistance setting and touch the probes to the element terminals for accurate results.
Pliers
Pliers help you disconnect and reconnect wires attached to the heating element. Needle-nose pliers work best for gripping small connectors and maneuvering in tight spaces. Use them to avoid damaging wires or terminals.
Tip: Always unplug your dryer before using any tools to prevent electrical hazards.
Replacement Parts for Maytag Electric Dryer
Compatible Heating Element
You should use a genuine OEM Maytag dryer heating element for best results. OEM parts, such as models 279838, WP3387747, WP8544771, and WPY503978, match your dryer’s specifications. These parts offer durability and precise fit, which helps maintain performance and safety. When you use genuine parts, you also protect your appliance warranty.
Replacement Screws (if needed)
Sometimes, original screws become stripped or lost during disassembly. Keep a set of replacement screws on hand to ensure you can secure all components properly. Using the correct screws prevents vibration and noise during operation.
Note: Check the thermal fuse when replacing the heating element. The fuse often fails at the same time and can cause similar symptoms.
Optional Supplies for a Smooth Repair
Work Gloves
Wear sturdy, well-fitting work gloves to protect your hands from sharp edges inside the dryer. Gloves also help you maintain a firm grip on tools and parts.
Vacuum or Brush for Cleaning
A vacuum cleaner with a hose attachment or a small brush helps you remove lint and dust from the heating element area. Cleaning the workspace reduces fire risk and improves dryer efficiency.
Quick Reference Table: Essential Tools and Supplies
| Tool/Supply | Purpose |
|---|---|
| Phillips Screwdriver | Remove/install screws |
| Flathead Screwdriver | Pry panels, remove/install screws |
| Nut Driver/Wrench | Remove hex head screws |
| Multimeter | Test electrical continuity |
| Pliers | Disconnect/reconnect wires |
| Work Gloves | Protect hands |
| Vacuum/Brush | Clean lint and dust |
By preparing these tools and parts, you set yourself up for a successful and safe heating element replacement. This preparation streamlines the dryer repair process and helps you avoid unnecessary delays.
Step-by-Step Guide to Replace Heating Element in Maytag Dryer
Accessing the Heating Element Assembly
Removing the Dryer Back Panel
Start by ensuring your safety. Unplug the dryer from its power source. Move the appliance away from the wall to access the rear. Use a Phillips screwdriver or nut driver to remove the screws securing the back panel. Set the screws aside in a safe place. Gently lift the back panel off and place it nearby. This step exposes the internal components and allows you to proceed with the repair.
⚠️ Safety Reminder: Always disconnect the dryer before starting any repair to prevent electrical shock.
Locating the Heating Element in Maytag Electric Dryer
Once you remove the back panel, look for the heating element assembly. In most Maytag models, you will find the heating element under the drum, positioned in the bottom right corner inside a silver canister. The assembly sits beneath the drum and connects to the heat duct. You may need to remove the lower front panel for easier access. Slide a putty knife along the top edge of the lower front panel to release the plastic clamps, then fold the panel down. This step gives you a clear view of the heating element and its housing.
For a visual walkthrough, you can reference video tutorials that demonstrate these steps in detail.
Removing the Faulty Heating Element
Disconnecting Wires and Terminals
Before you remove the heating element, identify all wires connected to it. Use needle-nose pliers to grip the wire connectors. Gently pull each connector off the terminal. Take note of each wire’s position or snap a photo for reference. This precaution ensures you reconnect everything correctly during reassembly. Disconnect any wires attached to the high-limit thermostat or thermal fuse on the heating element housing.
Unscrewing or Unhooking the Element Housing
Locate the screws or mounting clips that secure the heating element housing. Use a nut driver or socket wrench to remove these fasteners. Keep the screws in a small container to avoid losing them. Carefully slide the heating element assembly out of its compartment. If you encounter resistance, check for any hidden screws or clips. Avoid forcing the assembly, as this can damage internal parts. Once free, set the old heating element aside for disposal.
- Common challenges during this step include tight spaces and stubborn screws. Take your time and use the correct tools to avoid stripping fasteners.
Installing the New Heating Element
Securing the New Element in Place
Prepare the new heating element for installation. Position it inside the housing, ensuring the coil sits evenly and does not touch itself or the metal casing. Feed the coil ends through the insulator rings, keeping the spacing uniform. Use pliers to straighten the coil ends if necessary. Secure each end to the insulator posts with washers and nuts. Double-check that the coil remains evenly distributed and does not stretch. Join the two halves of the housing and fasten them with screws.
Slide the assembled heating element into the heat duct. Align it with the mounting holes and secure it with the original screws. Reattach the heating element shield if your model includes one.
Reconnecting Wires and Terminals
Reconnect all wires to their original terminals. Attach the high-limit thermostat wires and the power supply wire, securing them with nuts if required. Make sure each connection is tight and matches your reference photo or notes. Reinstall the front and back panels by reversing the removal steps. Secure all screws and ensure the panels fit snugly.
🛠️ Tip: Double-check every connection before restoring power. Loose wires can cause malfunction or safety hazards.
After you replace heating element components, plug the dryer back in. Run a short test cycle to confirm the appliance heats properly. If the dryer operates as expected, you have completed the repair successfully. This process restores your maytag dryer’s heating performance and extends its service life.
Reassembling and Testing Your Maytag Dryer
Reattaching the Back Panel
After you install the new heating element and secure all internal components, you need to reattach the back panel. Align the panel with the screw holes on the dryer’s frame. Hold the panel steady and insert each screw by hand to prevent cross-threading. Use your Phillips screwdriver or nut driver to tighten the screws in a crisscross pattern. This method helps distribute pressure evenly and ensures a snug fit.
Tip: If you find stripped or missing screws, replace them with new ones of the same size. A secure back panel reduces vibration and noise during operation.
Check the edges of the panel for gaps. Press along the perimeter to confirm the panel sits flush against the dryer body. A properly installed back panel protects internal wiring and components from dust and debris.
Double-Checking All Connections
Before you restore power, you must verify every connection inside the dryer. Inspect each wire attached to the heating element, thermostat, and thermal fuse. Tug gently on each connector to confirm it sits firmly on its terminal. Loose connections can cause intermittent heating or electrical arcing.
Use this checklist to guide your inspection:
- All wires reconnected to the correct terminals
- Screws and nuts tightened on the heating element housing
- High-limit thermostat and thermal fuse wires attached securely
- No wires pinched or trapped under the back panel
- No tools or foreign objects left inside the dryer
⚡ Alert: Never skip this step. Double-checking connections prevents electrical hazards and ensures your repair lasts.
If you took photos before disassembly, compare them to your current setup. This visual reference helps you spot any misplaced wires or missing fasteners.
Restoring Power and Running a Test Cycle
Once you confirm all connections and panels are secure, you can restore power to your Maytag dryer. Plug the power cord back into the wall outlet. If you turned off the circuit breaker, switch it back to the “on” position.
Set your dryer to a standard heat cycle and press “Start.” Observe the following during the test:
- The drum spins smoothly
- The heating element activates (you should feel warm air after a few minutes)
- No unusual noises, vibrations, or burning smells
Let the dryer run for 5–10 minutes. Open the door and check for heat inside the drum. If you notice any issues, such as a lack of heat or error codes on the display, unplug the dryer and review your installation steps.
🛠️ Pro Tip: Keep a notepad nearby to jot down any observations during the test cycle. This record helps you troubleshoot if problems arise.
If the dryer heats and operates normally, you have completed the repair successfully. You can now resume regular laundry routines with restored efficiency and peace of mind.
Troubleshooting Maytag Dryer After Heating Element Replacement
After you replace the heating element in your Maytag dryer, you might still encounter issues. Addressing these promptly ensures your appliance operates safely and efficiently.
Dryer Still Not Heating
If your dryer fails to produce heat after installing a new heating element, you need to perform a systematic check. Several components and conditions can prevent proper heating.
Checking Power Supply
Start by confirming your dryer receives the correct power. Electric dryers require a full 240 volts to heat. If only one breaker trips, the drum may spin, but the dryer will not heat. Follow these steps:
- Inspect your circuit breakers. Reset any that have tripped.
- Ensure the dryer is plugged in securely.
- Verify the outlet delivers 240 volts using a multimeter.
If your dryer settings are on “Fluff Air” or “Wrinkle Prevent,” the appliance will not generate heat. Always select a heat cycle for testing.
Inspecting Thermal Fuse and Thermostat
A blown thermal fuse or faulty thermostat can interrupt the heating circuit. Use a multimeter to test these components for continuity:
- Remove the back panel to access the thermal fuse and thermostats.
- Test the thermal fuse, high-limit thermostat, and cycling thermostat.
- Replace any part that does not show continuity.
You should also check the timer and control board if all other components test correctly. Sometimes, a faulty timer or control relay can cause dryer problems even after replacing the heating element.
Examining the Exhaust Vent
A blocked exhaust vent restricts airflow, causing the dryer to overheat and trip safety devices. Examine the vent for lint buildup or obstructions:
- Disconnect the vent hose and inspect for clogs.
- Clean the vent line and exterior vent cap thoroughly.
- Reconnect and ensure air flows freely.
Regular vent cleaning prevents overheating and extends the life of your dryer.
If you complete these steps and your dryer still does not heat, consider scheduling a professional repair. Some issues, such as wiring faults or control board failures, require advanced troubleshooting.
Unusual Noises or Smells
After a heating element replacement, you may notice new noises or odors. Identifying the source helps you prevent further damage.
Ensuring Proper Installation
Improper installation can cause burning smells or operational noise. Double-check that you secured all connections and panels. The following table outlines common causes and their effects:
| Cause | Explanation | Relation to Noises or Smells After Heating Element Replacement |
|---|---|---|
| Lint Buildup | Excess lint inside dryer and vent can catch fire or cause overheating. | Residual lint after replacement can cause burning smells and potential fire risk. |
| Terminal Block Issues | Loose or burnt connections at the terminal block can overheat and emit burning smells. | Improper reconnection during replacement can cause burning smells and electrical issues. |
| Idler Pulley or Drum Belt | Worn or stuck idler pulley or belt can cause unusual noises during operation. | Replacement process may disturb these parts, leading to noise if not checked or replaced. |
| Airflow Problems | Clogged or partly clogged vent lines block airflow, causing overheating and burning smells. | Vent cleaning often overlooked during heating element replacement, leading to overheating. |
Always remove lint and debris from the heating element area and vent system before reassembling your dryer.
Looking for Loose Parts
Loose screws or misplaced components can create rattling or thumping sounds. Inspect the drum belt, idler pulley, and all mounting hardware. Tighten any loose fasteners and ensure moving parts operate smoothly. If you detect a persistent burning smell, unplug the dryer immediately and recheck all electrical connections.
By following these troubleshooting steps, you address most common dryer problems after a heating element replacement. Careful inspection and maintenance help you restore safe, quiet, and efficient operation.
When to Call a Professional for Maytag Electric Dryer Repair
Even with careful installation, some dryer issues require expert attention. Recognizing when to seek professional help protects your safety and prevents further damage to your appliance.
Persistent Issues After Replacement
After you replace the heating element, your Maytag dryer should operate smoothly. If problems continue, you may face complex electrical or mechanical faults that go beyond basic repairs.
Electrical Problems
You might notice persistent control board malfunctions, sensor bar errors, or safety hazards such as exposed wires, sparking, or unusual odors. These issues often signal deeper electrical faults. If your dryer stops running, displays error codes, or the control panel becomes unresponsive, you should not attempt further repairs on your own. Sometimes, the dryer receives only partial voltage due to a tripped breaker, which allows the drum to spin but prevents heating. If you have checked the power supply and the problem persists, a licensed technician should diagnose the electrical system.
⚡ Alert: Never ignore flickering lights, sudden power loss, or exposed wiring. These signs indicate a risk of electrical shock or fire.
Repeated Heating Element Failure
If you replace the heating element and it fails again soon after, you likely face an underlying problem. Possible causes include a faulty thermostat, malfunctioning thermal fuse, or control board issues. Repeated failures suggest that the root cause remains unresolved. You should contact a professional for a thorough inspection and long-term solution.
Common persistent issues that require professional dryer repair include:
- Dryer stops running despite troubleshooting
- Unusual noises such as banging, grinding, or squeaking
- Excessive vibration during operation
- Malfunctioning control panel with error codes or unresponsiveness
- Ongoing problems after checking power supply, lint filter, and ventilation
Safety Concerns and Major Damage
Some situations present immediate safety risks or indicate significant mechanical damage. In these cases, professional intervention is essential.
Unfamiliarity with Electrical Repairs
If you feel uncomfortable working with electrical components or lack experience in appliance repair, you should not attempt complex fixes. Handling high-voltage parts without proper training increases the risk of injury. A certified technician has the tools and expertise to complete repairs safely.
Signs of Major Damage
Major damage often appears as grinding, rattling, or squeaking noises. You may notice uneven drum rotation, strong vibrations, or cycles ending prematurely. Flickering lights, sudden power loss, or error codes on the control panel point to wiring, sensor, or circuit board problems. Burned-out heating elements or tripped thermal fuses after prolonged use also signal deeper issues.
🛑 Note: If you see or smell smoke, unplug the dryer immediately and call a professional. Continuing to use a damaged appliance can cause fire or further mechanical failure.
The table below summarizes key warning signs that require immediate professional attention:
| Warning Sign | Possible Cause | Action Needed |
|---|---|---|
| Grinding, rattling, or squeaking noise | Worn drum belt, motor, or rollers | Professional diagnosis |
| Dryer runs but does not heat | Heating element or thermostat failure | Expert inspection |
| Flickering lights or power loss | Wiring or control board issues | Immediate service |
| Uneven drum rotation or strong vibration | Worn bearings or misaligned rollers | Mechanical repair |
| Error codes on control panel | Sensor or electronic failure | Authorized technician |
You protect your home and extend the life of your dryer by recognizing these signs and calling a professional when needed.
Maintenance Tips for Maytag Dryer Heating Element Longevity
Regular Cleaning and Care
Lint Trap and Vent Maintenance
You can extend the life of your Maytag dryer heating element by making cleaning a regular habit. Start with the lint filter. Remove lint from the filter before and after every load. This simple step keeps airflow strong and reduces fire risk. When lint builds up, your dryer works harder, which strains the heating element and shortens its lifespan.
At least once a year, perform a thorough cleaning of the dryer’s interior and venting system. Lint can hide inside the dryer cabinet, hoses, and ducts. Use a vacuum or brush to clear out these areas. Clean the vent line every one to two years, or sooner if you notice longer drying times. Proper airflow prevents overheating and helps your dryer run efficiently.
💡 Tip: Professional vent cleaning services and vent testing kits can help you maintain optimal dryer performance, especially if you have a long or complex vent system.
Key cleaning steps for dryer longevity:
- Clean the lint filter before and after every load.
- Remove lint from the dryer’s interior and vent system at least once a year.
- Clean dryer hoses and ducts periodically to maintain performance and safety.
- Inspect and replace the thermal fuse if you experience repeated heating element failures.
Proper Dryer Use Habits
Avoiding Overloading
You protect your heating element by loading your dryer correctly. Avoid overloading. Fill the drum no more than three-quarters full. Clothes need space to tumble freely. Overloading restricts airflow, which causes the heating element to overheat and wear out faster.
Separate heavy fabrics, such as towels, from lighter items. Drying similar fabrics together ensures even drying and reduces stress on the heating element. Remove excess moisture from clothes before placing them in the dryer. Use a high spin cycle in your washer or wring out wet items by hand.
- Load clothes loosely, leaving about 25% to 50% of the drum empty.
- Wash and dry even loads by grouping similar weights and bulk.
- Avoid mixing bulky and lightweight items in the same cycle.
Monitoring Drying Cycles
You can further protect your dryer by choosing the right settings. Use lower heat settings and shorter drying times when possible. High heat cycles can overwork the heating element. If your dryer has a moisture sensor, use it and clean the sensor monthly. This feature helps prevent over-drying and saves energy.
Always follow the manufacturer’s manual for recommended load sizes and cycle types. Regularly inspect the dryer vent system for blockages. Consider scheduling professional maintenance once a year to check the heating system and ensure safe operation.
🛠️ Note: Consistent care and smart usage habits help you avoid costly repairs and keep your Maytag dryer running efficiently for years.
You can replace a Maytag dryer heating element as a beginner by following clear steps and prioritizing safety.
- Always disconnect power before repairs.
- Use your owner’s manual to locate and test the heating element.
- Check fuses, breakers, and thermostats for proper function.
- If you feel unsure or face persistent issues, contact a professional.
Regular cleaning and careful use extend your dryer’s life. For complex problems, Sears Home Services offers expert Maytag dryer repair with experienced technicians.
FAQ
How often should you replace the heating element in your Maytag dryer?
You should replace the heating element only when it fails. Most heating elements last several years with proper care. Regular cleaning and correct dryer use help extend the lifespan of this part.
Can you use a generic heating element in your Maytag dryer?
You should use an OEM (Original Equipment Manufacturer) heating element for best results. Generic parts may not fit correctly or meet safety standards. Always check your model number before purchasing replacement parts.
What tools do you need to replace a Maytag dryer heating element?
You need a Phillips screwdriver, flathead screwdriver, nut driver or socket wrench, multimeter, and pliers. Work gloves and a vacuum or brush for cleaning can make the job easier and safer.
Is it safe to repair your Maytag dryer yourself?
You can safely repair your dryer if you follow all safety steps. Always unplug the appliance and wear protective gear. If you feel unsure or encounter electrical issues, contact a professional technician.
Why does your new heating element keep burning out?
A new heating element may fail quickly if airflow is blocked or if the thermal fuse or thermostat malfunctions. Clean the lint trap and vent regularly. Test related components to prevent repeated failures.
How do you know if the heating element is the problem?
You may notice the dryer runs but does not heat, or clothes take too long to dry. Use a multimeter to test the heating element for continuity. No continuity means you need a replacement.
Can you test the heating element without removing it?
You can test the heating element in place by accessing its terminals and using a multimeter. Always unplug the dryer before testing. If you cannot reach the terminals, you may need to remove the back panel.
What should you do if your dryer still does not heat after replacing the element?
Check the power supply, thermal fuse, and thermostats. Clean the exhaust vent. If the dryer still does not heat, consult a professional. Other electrical or control board issues may require expert diagnosis.
